Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp

Place of Origin shandong province
Brand Name SH
Certification ISO9001
Model Number MJH700E, MJH1000E
Minimum Order Quantity 1 SET
Price US $15,900 - 24,700 / Set
Packaging Details Container loading
Delivery Time within 20 days
Payment Terms T/T or L/C at sight, Western Union
Supply Ability 500Sets /year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition New Type Band Saw
Use Woodworking Style Horizontal
Voltage 380v/3phase/50HZ Or As Customer Needs Power(W) 22 Kw - 30 Kw
Warranty 12 Month After-sales Service Provided Engineer Available To Service Machine Overseas
Cut Max. Wood Diameter 700mm - 1000mm Operation Automatic
Leave a Message
Product Description

Hydraulic Band Sawmill Machine With Electric Motor

The max. cutting wood diameter can be customized as your requests




Model
MJH1000E MJH700E

Max Sawing Wood Diameter
1000mm 700mm

Saw Wheel Diameter
700mm 700mm

Max Sawing Wood Thickness
300mm 300mm

Standard Sawing Wood Length
4000mm 4000mm

Electric Motor Power
30kw 22kw

Up/Down Electric Motor
1.5kw 1.5kw

Forward/backward Electric Motor
2.2kw 2.2kw

Saw Blade Width
27mm-75mm 27mm-75mm

Blade Tension
Hydraulic Hydraulic

Machine Length
5800mm 5800mm

Weight
2500kg 2300kg



Standard Configuration
Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 0

Touch Screen Accuset Setworks

Automatically moves head for each cut and head walking speed is Frequency variable

Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 1

Hydraulic Clamp *1

Secure and stabilize the log

Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 2

Hydraulic Wood Clamp*4

Secure and stabilize the log

Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 3

Hydraulic vertical side supports *4

Secure and stabilize the log

Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 4

Hydraulic Log Loading

Arm *1

Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 5 Board automatic return hook
Optional parts:
Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 6

Mobile Wheels,

8 Adjustable Up/down legs

Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 7

Hydraulic bi-directional Chain log turner*2

For max. log control

Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 8 Hydraulic plank roller axle x1 Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 9 Extend The Rail Length



Mobile Portable Bandsaw Sawmill,Hydraulic Automatic Horizontal Log Band Saw with hydraulic clamp 10
