    Product Details:

    Place of Origin: shandong province
    Brand Name: SH
    Certification: CE
    Model Number: UN65 ,UN125, UN150

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: US $650-1,590 / Sets
    Packaging Details: iron frame packings
    Delivery Time: within 7 days
    Payment Terms: T/T or L/C at sight, Western Union
    Supply Ability: 300sets per month
    Contact Now
    Detailed Product Description
    Condition: New Use: Woodworking Bandsaw Blade Welding
    Warranty: 12 Months Voltage: 380v/3ph/50hz
    Dimensions:: 850*450*1050 Mm

    Flash Seal-welding Machine

    This welder is a special lever pressure type saw blade purpose welding machine,and during welding of saw blades,it needs no weld paste or solder.

    It is characterized by an extremely short welding duration and the low energy consumption,and in merely several seconds after being energized,it can surely weld saw blades together.

    It is low in cost and the quality of the resulted weld is much superior to that generated by traditional silver soldering or oxygen welding procedures.

    Technical Parameter
    UN65
    UN125
    UN150
    Welding Saw Blade Width (MM)
    15-60
    15-125
    15-150
    Welding Saw Blade Thickness (MM)
    0.5-1.15
    0.7-1.25
    0.7-1.25
    Voltage
    380V 50 HZ
    380V 50 HZ
    380V 50HZ
    Machine Weight (KG)
    110
    302
    308
    Machine Size(MM)
    650*350*800
    850*500*1050
    850*450*1180
    Package Weight (KG)
    118
    313
    318
    Package Size(MM)
    700*400*820
    900*520*1100
    900*500*1200


    Wood working band saw blade jointing machine /saw welding machine
