Wood Drying Kilns Wood Drying Chamber Timber Drying Kiln For Sale

Wood Drying Kilns Wood Drying Chamber Timber Drying Kiln For Sale

Wood Drying Kilns Wood Drying Chamber Timber Drying Kiln For Sale

Product Details:

Place of Origin: shandong province
Brand Name: SH
Certification: ISO
Model Number: 30cbm, 20cbm, 60cbm, 100cbm,etc

Payment & Shipping Terms:

Minimum Order Quantity: 1 SET
Price: US $5,000 - 20,000 / Set
Packaging Details: container loading
Delivery Time: within 15 days
Payment Terms: T/T or L/C at sight, Western Union
Supply Ability: 100 Sets/month
Contact Now
Detailed Product Description
Condition: New Type: Drum Drying Equipment
Voltage: 380V , 50HZ , 3 Phase Power(W): 10.6-24.2KW
Dimension: 6000x4500x4000MM Or Depends On Kiln Capacity Weight: 3000-6000KG
Warranty: 1 Year Fuel: Bark , Wood Shavings, Sawdust, Coal, Diesel, Gas
Structure: Upwind Structure After-sales Service Provided: Engineers Available To Service Machine Overseas

Wood Drying Kiln



1,Steam drying oven specialized in timber drying.



2,Non-pressure boilers,stable and durable,simple to install,safe and easy operation.



3,Combustion-supporting,Air blow and air return can be achieved by one wind turbine.



4,Fuel including bark,wood shavings,sawdust or coal.



5,Equipped with a steam generating device,oxygen air valve,return air valve,moisture removal system.



6,The drying media can be adjusted to reducing the possibility of inside crack,ends crack,surface crack,deformation and discoloration etc.



7,Low operating cost and high thermal efficiency. Recycling system to recycling the drying room heatings,greatly reduced the fuel consumption.



8,Box inwall is Aluminium,the out wall is color steel plate and the insulating layer is rock wool.



30 Cubic Meters Wood Drying Kiln

Item

Specification

QTY

Note

Drying Box

6000x4500x4000mm

1 Set



Box Base

Steel Tank

1 Set



Guide Plate

4500x4500mm

1 PCS



Stand Wall For Fan

4500x1000mm

1 PCS



Steam Drying Oven

YNM—20

1 Set

Automatic Feeding Water

Air Blower

4-72-4kw

1 Set



Chimney

Up-right 7.5Meter

1 PCS



Axle Fan

2.2kw

3 Sets

Hot and Humid

Control Cabinet



1 Set



High Temperature Wire



1 Set



Recycling Throat



1 PCS



Recycling Duct



1 Set



Steam Package



1 PCS



Steam Pipe



1 Set



Pipe Fitting



1 Set



Steam Spray Valve



1 Set



Drain Valve



1 PCS



Water Tank



1 PCS



Water Bucket



1 PCS



Outlet Temperature



1 PCS



Dry-bulb Thermometer



1 PCS



Wet-bulb thermometer



1 PCS



Moisture Exit



4 PCS



Door

Double Off

1 Set







50 Cubic Meters Wood Drying Kiln

Item

Specification

QTY

Note

Drying Box

7000x4500x5000mm

1



Box Base



1 Set



Steam Drying Oven

GHM—50

1 Set

Automatic Feeding Water

Air Blower

4-72-7.5kw

1 Set



Chimney

Up-right

7.5 Meters



Axle Fan

2.2 KW

4 Sets

Hot and Humid

Air Inlet Duct



1 Set



Recycling Throat



1 PCS



Recycling Duct



1 SET



Steam Package



1 PCS



Control Cabinet



1 Set



High Temperature Wire



1 Sets



Steam Valve



1 Pcs



Guide Plate

5500*4500

1 Pcs



Water Tank



1 Pcs



Water Bucket



1 Pcs



Outlet Temperature



1 Pcs



Dry-bulb Thermometer



1 Pcs



Wet-bulb thermometer



1 PCS



Moisture Exit



6 PCS



Stand Wall For Fan

4500*1000





Wood Drying Kilns Wood Drying Chamber Timber Drying Kiln For SaleWood Drying Kilns Wood Drying Chamber Timber Drying Kiln For SaleWood Drying Kilns Wood Drying Chamber Timber Drying Kiln For Sale
