Computer automatic type twin blades sliding table circular sawmill

Computer automatic type twin blades sliding table circular sawmill

    • Computer automatic type twin blades sliding table circular sawmill
    • Computer automatic type twin blades sliding table circular sawmill
    • Computer automatic type twin blades sliding table circular sawmill
    • Computer automatic type twin blades sliding table circular sawmill
    • Computer automatic type twin blades sliding table circular sawmill
  • Computer automatic type twin blades sliding table circular sawmill

    Product Details:

    Place of Origin: shandong province
    Brand Name: SH
    Certification: ISO
    Model Number: CT1500 CT2000 CT3000,TT1500/TT2000/TT3000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: US $2,900 - 7,500 / Set
    Packaging Details: iron made frame pallet
    Delivery Time: within 15 days
    Payment Terms: T/T, L/C, Western Union
    Supply Ability: 1000sets/year
    Contact Now
    Detailed Product Description
    Condition: New Type: Circular Rip Saw
    Use: Woodworking Style: Horizontal
    Voltage: 380V/3PH/50HZ Power(W): 7.5KW*2
    Dimension(L*W*H): 3000*1000*1500mm , 1300*700*1500mm Warranty: 12 Months
    After-sales Service Provided: Engineers Available To Service Machinery Overseas Operation: Touching Screen Auto Setworks
    Cutting Log Max. Diameter: 480mm

    Twin Blades Circular Sliding Table Sawmill- Computer type
    The round log can slitting naturally,slitting totally,can sawing round wood to square timber.
    The circular saw blade can avoid band saw blade bending,or dig hole on wood.
    The round log table saw mill is high safety ,high flatness of sawing surface,suitable for short wood,hard wood,large diameter wood.
    The production capacity is more than 4 timers than band sawmill.
    The specification is adjustable,Convenient to move the running rule,accuracy.
    The track use linear guideway,accuracy,no error,wear resistent.
    The machine have 2 separate motors,separate switches,Can only use one motor when sawing small diameter wood log.

    Technical Specifications:

    Model CT1500CT2000CT3000
    Max. saw log diameter:400mm400mm400mm
    Max. log length:1500mm2000mm3000mm
    Circular blade diameter:500mm500mm500mm
    Saw motor 7.5kw x 27.5kw x 27.5kw x 2
    Rail length 3500mm5000mm6500mm
    Wood fasten type pneumatic up/down
    Carriage rail linear axis linear axis linear axis
    Feeding type frequency variable speed adjustable
    Set sawn dimensionsTouching screen auto setworks

    Computer automatic type twin blades sliding table circular sawmill
    Heavy Duty Twin Blades Wood Circular Sawmill with Log Carriage- manual type

    ModelTT1500TT2000TT3000

    Max Sawing Wood Diameter
    400mm400mm400mm

    Max Sawing Wood Length
    1500mm2000mm3000mm

    Saw Blade Diameter
    500mm500mm500mm

    Motor Power
    7.5KW*27.5KW*27.5KW*2

    Rail Length
    3500mm5000mm6500mm

    Wood Fasten Model
    PneumaticPneumaticPneumatic

    Carriage Rail Model
    Linear AxisLinear AxisLinear Axis

    Optional part:
    1.Maximum sawing log diameter is upto 48cm .
    2.Can increase motor power as customer needs .
    Computer automatic type twin blades sliding table circular sawmill
    Heavy duty twin blades circular saw with log carriage-Diesel Engine Powered

    modelTTD400-1500TTD400-2000TTD400-3000
    Cut log max. diameter40 cm40 cm40 cm
    Cut length1.5m2m3m
    Blade diameter500mm500mm500mm
    Diesel engine, electric start40HP40HP40HP
    Track length3500mm5000mm6500mm
    Log clampingpneumaticpneumaticpneumatic
    Movement of carriagemanuallymanuallymanually
    Carriage Rail ModeLinear AxisLinear AxisLinear Axis



















    Computer automatic type twin blades sliding table circular sawmill
