    Product Details:

    Place of Origin: shandong
    Brand Name: SH
    Certification: ISO
    Model Number: SH1600-600, SH1400-600, SH1300-600, SH1300-800

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: US $18,000-4,9000 / Sets
    Packaging Details: container loading
    Delivery Time: within 20 days
    Payment Terms: T/T or L/C at sight
    Supply Ability: 300 sets/Year
    Contact Now
    Detailed Product Description
    Condition: New Capacity: 15-30tons/hour
    Electric Motor: 160kw Or As Customer Needs Feeding Inlet Size: 1300x600mm
    Roll Diameter: 830mm Or 1000mm Discharging Conveyor: 10meters
    Magnetic System: Optional For Nails Sucking Mobile Usage: 6pcs Wheels Optional

    SH1300-600 Series Wood Crusher Machine is mainly used for building film faced plywood, wasted wood pallet, Tree bark, Slabs, off cuts, branches, straw and so on. It can work together with the baler breaker. This machine includes Host, chain plate, feeding & outlet conveyor system, intelligent electrical control. Chain Plate Feeding conveyor feeds raw materials more freely, no need changing the belt all the time. It is with reasonable structure, simple operation, high automatic level, and high safety coefficient and production capacity, less manpower, easy maintenance. It is the ideal equipment for biomass power generation enterprises.

    Technical Parameter Of Host System Equipment



    Model SH1300-600
    Feeding Inlet 1300*600MM
    Blade Roller Diameter 830MM
    Blade Roller Speed 850RPM
    Capacity 15-20T/Hour
    YG8 Hammer Blade Quantity OR Blades 22 pcs hammers or 2sets blades
    Max Processing Wood Diameter 450MM
    Electric motor power  160KW
    Wood Chipper Size 20-40CM
    Working Life Of THE Hammer Blades 4000T-6000T





































    Technical Parameter Of Feeding System



    Model SH1300-600
    Slot Chain Plate Feeding Conveyor 1 Set
    Feeding Motor Power 7.5KW+11KW
    Chain Plate Width 1260MM
    Conveyor Length 6000MM
    Feeding Speed 2-18M/Min
    Chain Material 16Mn
    Position Limited Wheel 5
    Gear Box Hard Teeth Faces





























    Technical Parameter Of Discharging System

    Model SH1300-600
    Outlet Conveyor Belt 1Set
    First Outlet Motor 4KW With Gear Box
    Second Outlet Motor 5.5KW With Gear Box
    Conveyor Material 14-16# Channel/ Square Tube
    Conveyor Length*Width 10m*1m
    Conveyor Material Nylon 4 Layer
    Outlet Height 3800-4500MM



























    Intelligent Electronic Control System

    Model SH1300-600
    Large Control Cabinet Ground
    Host Start Model Soft Start
    Feeding Speed Control Model Variable Frequency
    Electrical Control Control Cabinet + Remote Control

    High Efficiency Hydraulic System

    Model SH1300-600
    Control Model Solenoid Valve
    Hydraulic Oil Pump 3KW
    Hydraulic Oil Tank 120L
