| Place of Origin: | shandong |
| Brand Name: | SH |
| Certification: | ISO9001 |
| Model Number: | SH216,SH218,SH2112，etc |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | US $3,500 - 40,000 / Set |
| Packaging Details: | container loading |
| Delivery Time: | within 15 days |
| Payment Terms: | T/T or L/C at sight, Western Union |
| Supply Ability: | 300 sets/quarter |
| Condition: | New | Warranty: | 12 Months |
|---|---|---|---|
| After-sales Service Provided: | Engineers Available To Service Machine Overseas | Type: | Wood Chipper |
| Use: | Chipping Wood,Chip Wood Branches | Capacity: | 3-10t/h |
| Raw Material: | Wood Log Or Waste Wood And Tree Branch | Operation: | Control Cabinet |
Drum clipper is a kind of specialized equipment to manufacture wood chip, which can be used for the manufacture of flake board, fiber board and paper. The small-sized drum clipper is the best equipment for labs of factories. Raw materials for drum clipper are thin timber, branches, remainder of wood processing (slab, batten, heart of log) and sugar cane stalk, reed, bamboo.
| Model | SH216 | SH218 | SH2112 |
| Blade Roll Diameter(mm) | 650 | 800 | 1000 |
| Blade Roll Length(mm) | 600 | 800 | 780 |
| Blade Quantity(Pcs) | 2 | 2 | 3 |
| Feeding Inlet(mm) | 300*600 | 380*700 | 550*800 |
| Blade Roll Speed (R/Min) | 650 | 650 | 500 |
| Feeding Speed(M/Min) | 33 | 35 | 38 |
| Max Processing Wood Diameter(mm) | 240 | 330 | 500 |
| Wood Chip Length(mm) | 20-30 | 20-30 | 20-50 |
| Production Capacity(T/H) | 7-10 | 25-30 | 30-40 |
| Main Motor Power(kw) | 55 | 110 | 160 |
| Feeding Roll Motor Power(kw) | 3*1 , 4*1 | 5.5*2 | 7.5*1,5.5*1 |
| Weight(t) | 4.5 | 7 | 12 |
| Overall Dimension(mm) | 2600*2100*1430 | 2670*2150*1500 | 4400*3700*2050 |
| Feeding Motor Power | 2.2KW | 3KW | 3KW |
| Oil Pump Motor Power(kw) | 1.5 | 1.5 | 1.5 |
| Feeding Conveyor Length | 6 Meters | 6 Meters | 8 Meters |
| Outlet Conveyor Length | 10 Meters | 10 Meters | 12 Meters |
Working video link: https://youtu.be/RoDzKCpTYKw Or https://youtu.be/EGsODQsUnYA / https://youtu.be/XQAKR3SUmIg
