vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine

vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine

    • vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine
    • vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine
    • vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine
    • vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine
    • vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine
    • vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine
  • vertical band sawmill with CNC carriage automatic wheel wood cutting saw machine

    Product Details:

    Place of Origin: shandong province
    Brand Name: SH
    Certification: ISO
    Model Number: MJ3212-Z5000,MJ3212-Z3000,MJ3210-Z5000,MJ3310-Z3000

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: US $5,000 - 50,000 / Set
    Packaging Details: container loading
    Delivery Time: within 15 days
    Payment Terms: T/T or L/C at sight, Western Union
    Supply Ability: 100 sets/quarter
    Contact Now
    Detailed Product Description
    Condition: New Type: Band Saw
    Usage: Woodcutting Voltage: 380v/3ph/50HZ Or As Customer Needs
    Warranty: 12 Months After-sale Service Provided: Engineers Available To Service Machines Overseas
    Name: Vertical Band Sawmill With CNC Carriage Max. Sawing Log Diameter: 1250mm

    Vertical Band Sawmill With CNC Log Carriage

    This lathe is mainly used to Vertical cut or slab-cut logs of a large or middle diameter or re-saw timbers into slabs and square logs of various specifications and it smoothly runs at a high efficiency.In combination with carriage, it will enlarge the working range and improve product quality and hence is the ideal equipment for wood working enterprises.

    Technical Parameter MJ3212-Z5000 MJ3212-Z3000 MJ3310-Z5000 MJ3310-Z3000
    Saw Wheel Diameter (MM) 1250 1250 1070 1000
    Saw Wheel Speed RPM 650 650 650 650
    Saw Blade Length (MM) 8600 8600 7400 7400
    Saw Blade Width(MM) 150 150 150 150
    Saw Clip Movement Motor( KW) 0.75 0.75 0.75 0.75
    Saw Wheel Movement Motor( KW) 0.75 0.75 0.75 0.75
    Main Motor Power( KW) 37 37 30 30
    Carriage Clip Stake Quantity 4 4 4 3
    Carriage Wheel Quantity 3 3 3 2
    forward and backward Electric Electric Electric Electric
    Sawing Thickness Setting Electric Electric Electric Electric
    Max Sawing Wood Diameter(MM) 1200 1200 1000 1000
    Max Sawing Wood Length(MM) 6000 4000 6000 4000
    Track Length(MM) 16000 12000 16000 12000
    Weight (KG) 7200 6500 4900 4200

    vertical band sawmill with CNC carriage automatic wheel wood cutting saw machinevertical band sawmill with CNC carriage automatic wheel wood cutting saw machinevertical band sawmill with CNC carriage automatic wheel wood cutting saw machine
