    Product Details:

    Place of Origin: shandong province
    Brand Name: SH
    Certification: ISO
    Model Number: BC380 BC400 BC500

    Payment & Shipping Terms:

    Minimum Order Quantity: 1 SET
    Price: US $1,900-15,500 / Set
    Packaging Details: wooden pallet or iron frame packings
    Delivery Time: within 20 days
    Payment Terms: T/T or L/C at sight, Western Union
    Supply Ability: 500sets/month
    Contact Now
    Detailed Product Description
    Condition: New Type: Circular Saw
    Use: Woodworking Style: Vertical
    Usage: Cutting Log Or Plate Into Boards Voltage: 380V/3phase/50HZ Or As Customer Needs
    Power(W): 7.5-13KW Dimension: 1200*1200*1500
    Weight: 150KG Warranty: One Year

    Multi-chip Sawmill
    Technical Parameter BC380 BC400 BC500
    Max sawing wood thickness 60mm 30mm 60mm
    Max sawing wood width 380mm 400mm 500mm
    Saw diameter 230mm 230mm 230mm
    Install power 7.5KW 5.5KW 13KW
    Saw number

    1P-5P



    1P-5P



    1P-5P



    Spindle speed 5800/min 5800/min 5800/min

    Cheap Plank Cutting Multi blade Rip Saw,wood cutting saw multi blades rip saw machine

    Multi blades Ripsaw for Round Log Cutting

    1.Cut logs into planks at several pieces per time.

    2.With log centering feeding conveyor

    3.Automatic controlling




    Technical data
    SHYM200 SHYM250 SHYM300 SHYM350 SHYM400 SHYM450

    Cutting diameter (mm)
    200 250 300 350 400 450

    Cutting length (mm)
    >600 >600 >600 >600 >600 >600

    Spindle speed (r/min)
    2800

    Main motor power (KW)
    22kw *2 22kw *2 30kw *2 37kw *2 45kw *2 50kw *2
    Feeding motor power (KW) 1.5 1.5 2.2 2.2 3 3

    Diameter of blade (mm)
    305 366 405 480 550 600

    Blade No. (pcs)
    2-10 2-10 2-10 2-10 2-10 2-10

    Blade arrangement
    Up/down Up/down Up/down Up/down Up/down Up/down

    Feeding speed
    frequency adjustable feeding control

    Cooling water pressure
    0.3-0.6PA

    Cooling mode
    Axial watering

    Cheap Plank Cutting Multi blade Rip Saw,wood cutting saw multi blades rip saw machine

    Cheap Plank Cutting Multi blade Rip Saw,wood cutting saw multi blades rip saw machine

    Multi Blades Ripsaw for Planks/Lumber Cutting

    1.Cut planks into smaller wood boards at several pieces per time.

    2.Automatic controlling


    SHBC Model data
    120-250 160-250 120-300 160-300 120-400 160-400

    Cut max. width (mm)
    120 160 120 160 120 160

    Cut max. thickness (mm)
    250 250 300 300 400 400

    Cut length(mm)
    >500 >500 >500 >500 >500 >500

    Spindle speed(r/min)
    2800 2800 2800 2800 2800 2800

    Main motor power(kw)
    15 x2 18.5 x2 22 x2 22 x2 15 x2 22 x2

    Feeding motor(kw)
    1.5 1.5 2.2 2.2 2.2 2.2

    Blade diameter(mm)
    212 255 255 255 255 255

    Blade No.(pcs)
    2-10 2-10 2-10 2-10 2-10 2-10

    Blade arrangement
    up/down up/down up/down up/down up/down up/down

    Feeding mode
    Frequency variable feeding

    Cooling water pressure
    0.3-0.6PA

    Cooling type
    Axial center spraying

    Cheap Plank Cutting Multi blade Rip Saw,wood cutting saw multi blades rip saw machineCheap Plank Cutting Multi blade Rip Saw,wood cutting saw multi blades rip saw machine
