6meters Log Cutting Double Blades Angle Circular Saw sawmill Machines with electric inverter

Basic Information
Place of Origin: shandong province, China
Brand Name: SH
Certification: ISO9001
Model Number: DS700 D1300,DS2000
Minimum Order Quantity: 1 SET
Price: US $8,700 - 14,800 / Set
Packaging Details: container loading
Delivery Time: within 15 days
Payment Terms: T/T or L/C at sight
Supply Ability: 500sets/year
Detail Information
Condition: New Application: Sawing Logs Into Square Timber
Guarantee: 1 Year Max. Sawing Log Diameter: 2000mm
Sawing Log Length: 6meters Or As Customer Needs Main Motor Power: 22KW Or As Customer Needs
Control: Distant Auto Setworks Circular Blade Diameter: 546mm Or 760mm
Highlight:

woodworking machine

,

circular saw

,

lumber sawmills


Product Description

Double Blades Angle Circular Saw Mill

Introduction :

1). The Sawmill is a versatile machine for the radial lumber, Pooh flooring material,carpenter lumber and palette lath production.

2). The Blades enables cutting in both directions,which considerably increases the cutting capacity.

3). Quick and accurate electronic positioning guarantee invariable high productivity and safety.

4). The angle circular saw is a machine that:

5). Produces lumber with saw-cut dimension accuracy up to ± 1mm

6). Produces lumber of excellent surface quality

7). Results in very low operational costs

8). Electric inverter crane,touch screen for length calculation and remote control.



Working video link : https://youtu.be/HZ9SHLVnE8I



Technical Specifications:



Model DS700 DS1300 DS1300A DS2000 DS2000A
Max Sawing Wood Diameter 700MM 1300MM 1300MM 2000MM 2000MM
Max Sawing Wood Size 150*150MM 210 * 210MM 300*210MM 210*210MM 300*210MM
Saw Blade Diameter 2*424MM 2*546MM

1*760mm,

1*546mm

2*546MM

1*760mm

1*546mm

Motors Power(KW)

5.5KW*2,

1.1KW*3

15KW*2,

1.1KW*3

22KW*1,

15 KW*1

1.1KW*3

15KW*2,

1.1KW*3

22KW*1,

15KW*1

1.1KW*3

Max Swing Wood Length 6 Meters 6 Meters 6 Meters 6 Meters 6 Meters
Machine weight 1500KG 2000KG 2500KG 2700KG

3000KG
