Large Bandsaw Mill 2500mm Dia Bandsaw Wood Saw Mill Automatic Sawmill Machine
| Place of Origin | Shandong Province, China |
|---|---|
| Brand Name | SH |
| Certification | ISO9001 |
| Model Number | MJ1200 MJ1500 MJ2000 MJ2500 |
| Minimum Order Quantity | 1 SET |
| Price | US $16,000 - 29,000 / Set |
| Packaging Details | container loading |
| Delivery Time | within 15 days |
| Payment Terms | T/T or L/C at sight, Western Union |
| Supply Ability | 500sets/year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Large Horizontal Log Saw Machine | Conditon | New |
|---|---|---|---|
| Type | Band Saw | Max. Sawing Length | 6meters Or Extend Sawmill Track For Free |
| Power | 55KW | Saw Wheel Diameter | 1070mm |
| Max. Cutting Width | 2500mm | Bandsaw Blade Size | 10500x125mm |
| Operation | PLC Touching Screen Automatic | Warranty | 12 Months |
| Voltage | 380V/3phase/50HZ Or As Customer Needs | After-sales Service Provided | Online Support,commissioning And Training |
| High Light | 55KW Large Bandsaw Mill,2500mm Dia Bandsaw Wood Mill,Large Bandsaw Mill 2500mm Dia |
||
Product Description
Large horizontal log saw machine, Automatic Saw Machines for big diameter wood sawing
Heavy Duty Large Size Horizontal Band Sawmill
The Sawmill is designed to saw the large diameter hard woods like Rosewood ,wenge and santos rosewood.
It have large saw wheel and high power.
Owe reputable position to the steady performance of sawing the large diameter wood in Congo,Cabon, Angola, Fiji and Southeast Asian countries .
Technical specifications:
| Model | MJ1200 | MJ1500 | MJ2000 | MJ2500 |
| Max. sawing width | 1200mm | 1500mm | 2000mm | 2500mm |
| Height from blade to track | 1100mm | 1200mm | 1700mm | 2200mm |
| Saw wheel diameter | 1070mm | 1070mm | 1070mm | 1070mm |
| Max.sawn thickness | 350mm | 350mm | 400mm | 400mm |
| Sawing wood length max. | 6meters | 6meters | 6meters | 6meters |
| Saw blade length & width | 7900 &125mm | 8600&125mm | 9700&125mm | 10500&125,150mm |
| Main motor power | 30kw | 37kw | 45kw | 55kw |
| Weight | 3800kgs | 4500kg | 5000kg | 5500kg |
Detailed Image
Sawmill track
Optional parts - free base ground sawmill track
Diesel Engine Powered Large Size Horizontal Band Sawmill
| Technical specification | MJ2000D |
| Cut max. diameter (mm) | 2000 |
| Saw wheel diameter (mm) | 1070 |
| Cutting thickness (mm) | 10-400 |
| Cut length (m) | 10m |
| Band saw blade size (mm) | 1.25x125/150x9800 |
| Saw Walking | Frequency variable |
| Saw blade tension | electrical |
| Saw Elevating | Electrical |
| Main motor | 60HP Diesel engine |
| Total weight (kgs) | 5500 |
