| Place of Origin: | shandong province |
| Brand Name: | SH |
| Certification: | ISO |
| Model Number: | MJ3212-ZD5000,MJ3212-ZD3000 |
| Minimum Order Quantity: | 1 SET |
|---|---|
| Price: | US $19,900 - 50,000 / Set |
| Packaging Details: | container loading |
| Delivery Time: | within 20 days |
| Payment Terms: | T/T or L/C at sight, Western Union |
| Supply Ability: | 1500sets/year |
| Condition: | New | Type: | Band Saw |
|---|---|---|---|
| Usage: | Woodworking | Warranty: | 12 Months |
| After-sale Service Provide: | Engineer Available To Service Machine Overseas | Voltage: | 380V/3PH/50HZ Or As Customer Needs |
| Style: | Vertical | Cutting Log Maximum Diameter: | 1200mm |
| Cutting Log Length: | 4m/6meters Or As Customer Needs | Main Motor Power: | 37KW |
| Saw Walking: | Frequency Variable Speed Adjustable | Operation: | PLC Touching Screen Auto Setworks |
| Wood Grasp: | Electric |
MJ3212 Vertical Band Sawmill With CNC Log Carriage
This lathe is mainly used to Vertical cut or slab-cut logs of a large or middle diameter or re-saw timbers into slabs and square logs of various specifications and it smoothly runs at a high efficiency.In combination with carriage, it will enlarge the working range and improve product quality and hence is the ideal equipment for wood working enterprises.
| Technical data | MJ3212-ZD3000 | MJ3212-ZD5000 |
| Saw wheel diameter | 1250mm | 1250mm |
| Maximum sawing log diameter | 1200mm | 1200mm |
| Maximum sawing log length | 4meters | 6meters |
| Main motor | 37KW | 37KW |
| Saw blade L*W*T | 8600x150x1.25mm | 8600x150x1.25mm |
| Carriage clip stake quantity | 3sets | 4sets |
| Wood grasp mode | Electric | Electric |
| Carriage walking/advance | Frequency converter | Frequency converter |
| Setting sawn size | PLC touching screen | PLC touching screen |
| Carriage length | 3meters | 5meters |
| Rail length | 10meters | 18meters |
| Weight | 7500kgs | 8000kgs |
