Also called Wood Wool Machine,Wood Wool Mill or Wood Silk Machine.
The excelsior is widely used for animal bedding,handicraft packing,sound insulation board,fiber board production.
|
Model |
SHMS500-1 | SHMS500-2 | |
|
Processing Log Length
|
300-500mm | 300-500mm | |
|
Max Processing Log Diameter
|
160mm | 160mm x 2 | |
|
Blade Quantity
|
2 | 2 | |
|
Excelsior Width
|
1mm-10mm | 1mm-10mm | |
|
Excelsior Thickness
|
0.1mm-1mm | 0.1mm-1mm | |
|
Excelsior Length
|
300-500mm | 300-500mm | |
|
Motor Power
|
9kw | 16.5KW | |
|
Production Capacity
|
50-100kg/hour | 100-150KG/Hour |
|
Model SHMS500-2
Model SHMS500-2 made for one big log
Model SHMS500-1
Wood Wool Rope Firelighter Making Machine
|
Rope Size |
10-30MM |
|
Motor |
3KW |
|
Overall Size |
4100*810*1000MM |
|
Capacity |
200-450meters/hour |
|
Feeding type |
Automatic |
|
Weight |
570KG |
Wool Rope Cutter
|
Motor power |
3kw |
|
Cutting speed |
150~200times/min |
|
Short rope length |
3-5cm |
|
Overall size |
2060x650x950mm |
|
Weight |
182kgs |
Spare Parts-Optional
Spare parts of Wood Wool Machine
|
Item |
Quantity (one year usage ) |
|
Excelsior blade |
3 |
|
Flat blade |
3 |
|
one-way bearing SKF |
2 |
|
V-blet |
1 |
|
FL204 bearing SKF |
4 |
|
Travel switch |
1 |
|
Slider bearing SKF |
4 |
|
screw for tightening wood 45#steel |
1 |
|
|
Total |
Blade
Sharpener
Wood Shaving Machine
Process wood sticks,twigs,branches,wood scraps into shaving.
Adjust the size and thickness of the wood shaving.
It is the material for Plywood,furniture or paper factory.
Add as filler to prevent damage when transport some fragile items.
Use as nest shavings filler in poultry or animal breeding.
Bio-energy ignition material.
| Model | SHBH500-2 | SHBH500-4 | SHBH500-6 |
| Max Processing Length | 800MM | 1400MM | 1400MM |
| Max Processing Width | 500MM | 500MM | 500MM |
| Axle Quantity | 2 | 4 | 6 |
| Blade Quantity | 8 | 16 | 24 |
| Speed (r/min) | 4500 | 4500 | 4500 |
| Hopper Length (mm) | 800 | 1400 | 1400 |
| Total Power (kw) | 10.5KW | 18.5KW | 25.5KW |
| Shaving Depth(mm) | 1-5 | 1-5 | 1-5 |
| Production(KG/Hour) | 500 | 1000 | 1500 |
| With pneumatic press cover | |||
