Big Size Wood Bandsaw Machine , Portable Band Sawmill For Wood Cutting , Wood Band Saw Mill Machine Horizontal
| Place of Origin | Shandong Province, China |
|---|---|
| Brand Name | SH |
| Certification | ISO9001 |
| Model Number | MJ700, MJ1000, MJ1300, MJ1600 |
| Minimum Order Quantity | 1 SET |
| Price | US $4,200 - 10,200 / Set |
| Packaging Details | iron frame pallet or paper carton packings |
| Delivery Time | within 15 days |
| Payment Terms | T/T or L/C at sight, Western Union |
| Supply Ability | 1000sets/year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Electric Portable Sawmill / Horizontal Band Saw Machine | Saw Wheel Diameter | 700mm |
|---|---|---|---|
| Max. Sawing Wood Width | 1600mm, 1300mm, 1000mm, 70mm | Carbide Blade Width | 0.9 Thickness X 75mm Width |
| Saw Head Walking | Automatic Frequency Speed Adjustable | Sawing Log Max. Length | 4500mm Or As Customer Needs |
| Weight | 1100kgs To 1500kg | Dimension(l*w*h) | 3200*1900*2250mm |
| Application | Wood Saw,wood Industry,Wood Factory | Keyword | Wood Cutting Band Saw,Horizontal Band Sawmill,sawmill |
| High Light | Big Size Wood Bandsaw Machine,Horizontal Wood Band Saw Mill Machine,Wood Cutting Portable Band Sawmill |
||
Product Description
Portable Horizontal Wood Cutting Bandsaw Sawmill For Sale ,wood bandsaw sawmill
The portable horizontal band sawmill is designed to meet the requirements of customers in Africa ,South America and eastern europe.
- It is simple installation,easy operation,labor saving,and high productivity.
- This machine can be drived by either electric motor or diesel engine.
- It is widely used by the timber processing enterprises in the virgin forests areas.
CNC Horizontal Band Sawmill
| Model | MJ700 | MJ1000 | MJ1300 | MJ1600 |
|
Max. Sawing Wood Diameter |
700MM | 1000MM | 1300MM | 1600MM |
|
Saw Wheel Diameter |
600MM | 700MM | 700MM | 700MM |
|
Sawing Wood Thickness |
2-250MM | 2-300MM | 2-300MM | 2-300MM |
|
Sawing Wood Length MM |
1300-4500 | 1300-4500 | 1300-4500 | 1300-4500 |
|
Main Motor Power |
15KW | 18.5KW | 22KW | 30KW |
|
Lifting Motor Power |
1.5KW | 1.5KW | 1.5KW | 1.5KW |
| Walking motor power | 2.2kw | 2.2kw | 2.2kw | 2.2kw |
|
Total Weight (KG) |
1100 | 1100 | 1300 | 1500 |
Images:
Optional - Pneumatic log clamping
Optional - Board returning hook
Optional - Mobile usage + hydraulic log loading arm
|
PORTABLE ELECTRIC HORIZONTAL BAND SAWMILL -electrical |
||||
|
Technical Parameter |
MJ700E | MJ1000E | MJ1300E | MJ1600E |
|
Max. Sawing Wood Diameter |
700MM | 1000MM | 1300MM | 1600MM |
|
Saw Wheel Diameter |
600MM | 700MM | 700MM | 700MM |
|
Sawing Wood Thickness |
2-250MM | 2-300MM | 2-300MM | 2-300MM |
|
Sawing Wood Length MM |
1300-4500 | 1300-4500 | 1300-4500 | 1300-4500 |
|
Main Motor Power |
15KW | 18.5KW | 22KW | 30KW |
|
Lifting Motor Power |
1.5KW | 1.5KW | 1.5KW | 1.5KW |
|
Total Weight (KG) |
600 | 1100 | 1300 | 1500 |
Related Products
Wood Board Edger Saw
Technical data:
| Model | EG600A | EG800 | EG1000 |
| Max. Processing width | 600mm | 800mm | 1000mm |
| Min. Processing width | 50mm | 50mm | 50mm |
| Max. Processing height | 70mm | 70mm | 70mm |
| Blade | 2*350mm | 2*350mm | 2*350mm |
| Feeding method | Automatic feeding conveyor | ||
| Feed Rate | 20-25m/ minute, speed adjustable | ||
| Electric motor power | 7.5KW x 2sets | 7.5KW x 2sets | 7.5KW x 2sets |
| Machine weight | 1000KG | 1600KGS | 1800KGS |
|
Customize: Working electric voltage, bigger motor power |
|||
