Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine

  • Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine
  • Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine
  • Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine
  • Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine
  • Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine
  • Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine
Place of Origin Shandong Province, China
Brand Name SH
Certification ISO9001
Model Number YB1560B,YB2080,YB30100,YB60120
Minimum Order Quantity 1 SET wood round rod/stick milling machine for mop/swob
Price $1,900.00 - $5,000.00/ set
Packaging Details container loading or iron frame export pallet packing
Delivery Time within 15 days
Payment Terms T/T, Western Union
Supply Ability 300 Set/Sets per Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name Wood Round Rod/stick Milling Machine Application Processing Wood Logs Into Round Shape
Processing Log Diameter 15 -120mm Processing Log Length Min.600mm
Main Motor 3kw, 4kw, 5.5kw, 7.5kw Feeding Motor 0.75kw
Feeding Speed 3-5m/min Weight 450kgs To 800kgs
Warranty 1 Year After-sales Service Provided Video Technical Support,Online Support,Free Spare Parts
High Light

Broom Handle Wooden Stick Making Machine

,

Broom Stick Multi Blades Saw Machine

,

Wood Rod Multi Rip Saw Machine
Leave a Message
Product Description

Wood Round Rod Milling Machine, Machine For Making Wood Round Rod Milling

Wood round rod/stick milling machine for mop/swob

  • Introduction

This wood round rod/stick milling machine for mop/swob delivers power and performance in a compact size to help you work in the tightest applications. Its ability to fit through different log diameter makes it an excellent machine for indoor demolition work.

  • FEATURES AT A GLANCE

Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 0Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 1Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 2



  • PRODUCT SPECIFICATIONS
Model YB1560B YB2080 YB30100 YB60120
Process log diameter 15-60mm 20-80mm 30-100mm 60-120mm
Min process log length 600mm 600mm 600mm 600mm
Main Motor 3kw 4kw 5.5kw 7.5kw
Feeding Motor 0.75KW 0.75KW 0.75KW 0.75KW
Feeding speed Frequency 3-5m/min
Feeding wheel double feed double outlet
Dimension 1100*650*1100 1250*650*1100 1300*700*1100 2200*900*1200
Weight 450kg 520kg 700kg 800kg

Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 3

Ring Type Log Debarker

  • Technical data



Model SHHB220 SHHB260 SHHB320
Blade Disk Diameter 560MM 560MM 560MM
Blade Quantity 4 4 4
Log Diameter 60-220MM 100-260MM 150-320MM
Feeding Speed M/MIN 8.3 8.3 8.3
Debarking Rate 98% 98% 98%
Motor Power 6.2KW 6.2KW 6.2KW
  • Image

Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 4Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 5

Single Roll Log Debarker

Introduction:

  • The log debarker machine is used to take off the skins of round logs .
  • Processing log max. diameter : 320mm
  • Processing log max. length: 9meters
  • Peeling rate:98%

Specification:

Model SHBP6000 SHBP9000
Capacity Ton/Hour 5-10 10-15
Motor Power 37KW 45KW
Log Diameter 15-320mm 15-320mm
Debarking Rate 98% 98%
Max Log Length 6000mm 9000mm
Weight 4 5





























Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 6



Double Rolls Log Debarker

Model SHBPD4500 SHBPD6000 SHBPD9000
Capacity TON/HOUR 3-6 5-10 10-15
Motor Power 7.5kw*2 11*2 15*2
Log Diameter 50-250mm 50-250mm 50-250mm
Debarking Rate 98% 98% 98%
Max Log Length 4500mm 6000mm 9000mm
Overall Size 5.8*1.6*2 7.5*1.6*2 11*1.6*2
Weight 4 4 5

































Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 7

Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 8

Broom Handle Round Wooden Stick Making Machine Broom Stick Multi Blades Saw Machine 9
