Multiple Blade Circular Sawmill Wood Saw Machine for Panel Cutting
Double Spindle Panel Cutting Multiple Blades Rip Saw
1.Used for Lumber/Panels/Planks Cutting
2.Max. cutting depth/thciness is upto 160mm
3.Max. cutting width is upto 400mm
4.Big motor power, fit for hardwood cutting
5.Blades is placed on up/down abrod/spindle .
6.We present one set discs on your cutting thickness
Specifications:
Multi Blades Rip Saw- For wood panels/pkank cutting
Double Spindle Panel Cutting Multiple Blades Rip Saw -Heavy Duty Type
Related Ripsaw Machine
Multi Blades Rip Saw for wood boards cutting
Introduction:
Technical data :
| Model | HW500 | HW800 |
| Sawing thickness | 15-50mm | 15-50mm |
| Sawing width | 500mm | 800mm |
| Circular blade diameter | 230mm | 230mm |
| Electric motor | 15KW | 18.5KW |
| Blade qty | 1P-6P | 1P-10P |
| Rotation speed | 3500/min | 3500/min |
Photos:
Single Spindle Multi Rip Saw
| Model | BC150 | BC200 | BC300 |
| Max Sawing Wood Width | 150mm | 200mm | 300mm |
| Max Sawing Wood Thickness | 2-65mm | 2-65mm | 2-65mm |
| Min Sawing Wood Length | 200mm | 200mm | 200mm |
| Saw Blade Diameter | 250mm | 250mm | 250mm |
| Main Motor Power | 11kw | 15kw | 18.5kw |
| Pneumatic Press Roller,Variable Frequency Speed Adjustable Feeding | |||
| Model | BC380 | BC400 | BC600 |
| Max Sawing Wood Thickness | 15-50mm | 8-30mm | 15-50mm |
| Max Sawing Wood Width | 380mm | 400mm | 600mm |
| Min Sawing Wood Length | 450mm | 450mm | 450mm |
| Saw Blade Diameter | 230*50mm | 150*35mm | 230*60mm |
| Motor Power | 7.5KW | 4KW | 18.5KW |
