Wood Edger Cutting Circular Blade Table Sawmill
Introduction:
Technical data:
| Model | BT3000-600 | BT3000-1000 | BT3000-1500 |
| Sawing thickness | 10-180mm | 10-180mm | 10-180mm |
| Sawing maximum length | 3000mm | 3000mm | 3000mm |
| Sawing maximum width | 600mm | 1000mm | 1500mm |
| Circular blade diameter | 500mm | 500mm | 500mm |
| Motor power | 11KW | 15KW | 15KW |
| Track length | 5800mm | 5800mm | 5800mm |
| Wood grasp type | Pneumatic | Pneumatic | Pneumatic |
| Feeding | Manual | Manual | Manual |
| Operation | Manual | Manual | Manual |
Optional parts: 1.Frequency variable auto feeding ; 2. Saw track can be extended ; 3. Manual operation can be changed to electric type or PLC touching screen auto setworks | |||
Other type Board Edger Saw
| Model | EG600A | EG800 | EG1000 |
| Max. Processing width | 600mm | 800mm | 1000mm |
| Min. Processing width | 50mm | 50mm | 50mm |
| Max. Processing height | 70mm | 70mm | 70mm |
| Blade | 2*355mm | 2*355mm | 2*355mm |
| Feeding method | Automatic feeding conveyor | ||
| Feed Rate | 20-25m/ minute, speed adjustable | ||
| Electric motor power | 7.5KW x 2sets | 7.5KW x 2sets | 7.5KW x 2sets |
| Machine weight | 1000KG | 1600KGS | 1800KGS |
| Package size | 2920X1760X1800MM | 2920X1960X1800MM | 2920X2200X1800MM |
Customize: Working electric voltage, bigger motor power | |||
Heavy Duty Single Shaft Multi Blade Rip Saw / Board Edger Saw Machine
Introduction:
Technical data :
| Model | ZHW800-70 | ZHW800-80 | ZHW800-100 |
| Sawing wood height | 10-70mm | 10-80mm | 20-100mm |
| Sawing wood width | 800mm | 800mm | 800mm |
| Carbide blade diameter | 280mm | 305mm | 355mm |
| Main motor | 22KW | 30KW | 37KW |
| Blade quantity | 1P-10P | 1P-10P | 1P-10P |
| Rotation speed | 3500/min | 3500/min | 3500/min |
