Width 1000mm Sawmill Board Edger Sawing Board Lumber Edger
| Place of Origin | Shandong Province, China |
|---|---|
| Brand Name | SH |
| Certification | ISO9001 |
| Model Number | EG600, EG800, EG1000 |
| Minimum Order Quantity | 1 SET |
| Price | US $2,900 - 15,000 / Set |
| Packaging Details | iron made frame pallet |
| Delivery Time | within 15 days |
| Payment Terms | T/T or L/C at sight, Western Union |
| Supply Ability | 1000sets per year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Wood Edger Saw Machine | Application | Sawing Board Twin Edges At Same Time |
|---|---|---|---|
| Power | 15KW | Power Supply | 380v/3Phase/50HZ Or As Customer Needs |
| Sawing Max. Width | 600mm, 800mm, 1000mm | Sawing Max. Height | 70mm |
| Blades Moving | Auto Moving By Electric Button | Warranty | One Year |
| High Light | Width 1000mm Sawmill Board Edger,Sawing Board Lumber Edger,1000mm Sawmill Board Edger |
||
Product Description
Lumber Edger Twin Blade Board Edger Woodworking Saw, Wood Edger with max. width1000mm
Twin Blades Wood Board Edger/border cutting machine
1. Twin circular blades saw.
2. ONe blade is fixed, another is moveable ,saving working time, improve working efficiency.
3. With tyres, moveable usage is workable
4. The saw blade moves with infrared light and moves at the same time .
Technical data :
| Model | EG600 | EG800 | EG1000 |
| Sawing width | 50-600MM | 50-800MM | 50-1000MM |
| Sawing height | 10-70mm | 10-70mm | 10-70mm |
| Blade diameter | 2*350MM | 2*350MM | 2*350MM |
| Feeding speed | 20-25m/ minute | 20-25m/ minute | 20-25m/ minute |
| Main motor power | 7.5KW*2 | 7.5KW*2 | 7.5KW*2 |
Photos:
Single Blade Board Edger
1. With one piece circular blade fixed .
2. With 13HP USA Kolher gasoline engine powered.
3. Easy usage and transportable
4. Cutting length is as customer needs
5. Roller conveyor is easy for wood feeding and discharing .
Specifications:
| Single blade board edger (blade fixed) | |
| Max. sawing width with baffle rising | 350mm |
| Max. sawing width with baffle down | 500mm |
| Circular blade diameter | 355mm |
| Feeding roller length | 1500mm |
| Discharging roller length | 1500mm |
| Engine | 13HP Kolher petrol engine |
Working video link : https://youtu.be/wwB7MJA02nU
Photos:
Multi Blades Rip Saw
Introduction:
- with Infrared positioning
- for board edges cutting
- sawing planks into small pcs
- easy usage, no installation
Technical data :
| Model | HW500 | HW800 |
| Sawing thickness | 15-50mm | 15-50mm |
| Sawing width | 500mm | 800mm |
| Circular blade diameter | 210mm | 210mm |
| Electric motor | 15KW | 18.5KW |
| Blade qty | 1P-6P | 1P-10P |
| Rotation speed | 3500/min | 3500/min |
Photos:
Heavy Duty Single Shaft Multi Blade Rip Saw / Board Edger Saw Machine
Introduction:
- with Infrared positioning
- for big thickness board edger cutting
- high working efficiency, low cost ,fulfil the max. value of the wood
- easy usage, no installation
Technical data :
| Model | ZHW800-70 | ZHW800-80 | ZHW800-100 |
| Sawing wood height | 10-70mm | 10-80mm | 20-100mm |
| Sawing wood width | 800mm | 800mm | 800mm |
| Carbide blade diameter | 280mm | 305mm | 355mm |
| Main motor | 22KW | 30KW | 37KW |
| Blade quantity | 1P-10P | 1P-10P | 1P-10P |
| Rotation speed | 3500/min | 3500/min | 3500/min |
