Place of Origin: | Shandong Province, China |
---|---|
Brand Name: | SH |
Certification: | ISO9001 |
Model Number: | SHJM800, SHJM400, SHJM650, SHJM1000 |
Minimum Order Quantity: | 1 SET |
Price: | US $7,500 - 13,000 / Set |
Packaging Details: | container loading |
Delivery Time: | within 15 days |
Payment Terms: | T/T or L/C at sight, Western Union |
Supply Ability: | 300sets/year |
Name: | Wood Mill Precision Band Saw Sawmill For Thin Wood Cuts | Type: | Band Saw |
---|---|---|---|
Style: | Horizontal | Voltage: | 380V/3phase/50HZ Or As Customer Needs |
Power(W): | 18.5kw | Max. Sawing Width: | 650mm |
Dimension(L*W*H): | 3000 X 2230 X 2050MM | Weight: | 2550kg |
Warranty:: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machine Overseas |
Highlight: | saw,electric saw,portable sawmill |
1. No need installation, easy working with high efficienty, high precision.
2. Used to saw wood board/lumber into thin lumber/timber.
3. Re-saw working.
Model | SHJM-400 | SHJM-650 | SHJM-800 | SHJM-1000 |
Saw wheel diameter | 600MM | 700MM | 700MM | 700MM |
Max. processing width | 400MM | 650MM | 800MM | 1000MM |
Max. processing height | 110MM | 110MM | 110MM | 110MM |
Sawn min.thickness | 2MM | 2MM | 2MM | 2MM |
Feeding speed | 0.1-30m/min | 0.1-30m/min | 0.1-30m/min | 0.1-30m/min |
Main motor power | 15KW | 18.5KW | 22KW | 30KW |
Feeding motor power | 0.75KW | 0.75KW | 1.5KW | 1.5KW |
Sawn sizes setting | CNC digital | CNC digital | CNC digital | CNC digital |
Machine weight | 1850kgs | 2550kgs | 2750kgs | 3150kgs |
Detailed Image
Related Saw Machine
Diesel Engine Powered Horizontal Portable Band Sawmill
Technical Parameter |
MJ700P | MJ1000D | MJ1300D | MJ1600D |
Sawing Wood width max. |
700MM | 1000mm | 1300mm | 1600mm |
Saw Wheel Diameter(MM) |
600mm | 700mm | 700mm | 700mm |
Sawing Wood Thicknes |
10-200mm | 10-300mm | 10-300mm | 10-300mm |
Sawing Wood Length (MM) |
1300-4500 | 1300-4500 | 1300-4500 | 1300-4500 |
Engine |
22HP Petrol | 22HP Diesel | 25HP Diesel | 27HP Diesel |
Band Saw Blade Length |
5500mm | 6100mm | 6600mm | 7100mm |
Machine Length(MM) |
5800 | 5800 | 5800 | 5800 |
Total Weight (KG) |
1100 | 1100 | 1300 | 1500 |
Optional Parts: Extend sawmill track
Optional Parts: wheel for mobile usage
Optional Parts: Hydraulic log loading arm
Optional Parts: Hydraulic log loading arm +Inverter feeding +Touching screen auto setworks
