SW26G Gasoline Portable Band Sawmill Machine For Wood Cutting, Log Cutting Mobile Sawmill

1 SET
MOQ
US $1,788 - 2,988/ Set
Price
SW26G Gasoline Portable Band Sawmill Machine For Wood Cutting, Log Cutting Mobile Sawmill
Features Gallery Product Description Request A Quote
Features
Specifications
Name: Portable Sawmill
Condition: New
Type: Band Saw
Application: Wood Factory
Band Wheel Diameter: 480mm
Max. Sawing Log Diameter: 26''
Saw Head Walking: Manual
Sawing Log Length: 3meters Or As Customer Needs
Blade Size: 3750 X 35x 0.9 Mm
Color: Customized
Warranty: 1 Year
After-sales Service Provided: Online Support,commissioning And Training
Basic Infomation
Place of Origin: shandong province, China
Brand Name: SH
Certification: ISO9001
Model Number: SW26G, SW26E, SW26D
Payment & Shipping Terms
Packaging Details: iron frame pallet or film wrapped packings
Delivery Time: within 20 days
Payment Terms: T/T or L/C at sight, Western Union
Supply Ability: 1000sets/year
Product Description

SW26 Sawmill

  • Simple- Compact -Convenient
  • Reach your sawing petential with a tibery SW26 personal sawmill
  • The SW26 has a sleek design and all the great features of more expensive sawmill, including ceramic blade guides, quick-set log rests, and hand crank head adjustment.
  • The lightweight head and adjustable bed provide a variety of travel and storage options.

Technical Specifications:

Model SW26G SW26E
Power

Gasoline engine 9HP,

manual start

Electric 7.5KW, 3PH
Max Sawing Wood Diameter 660mm(26”) 660mm(26”)
Standard Sawing Wood Length 3000mm(118”) 3000mm(118”)
Saw Wheel Diameter 480mm(18.9”) 480mm(18.9”)
Blade size 3750 x 35x 0.9 mm(148”*1.37”*0.035”)
Machine Length 4000mm(157”) 4000mm(157”)
Weight 500KG 500KG
Packing size 2200mm*1000mm*1600mm







































Optional Parts:

1 Rail Extending
2 Wheels + lifting legs
3 Diesel Engine 13HP, electric start
4 Carbon bandsaw blade 3750*35*0.9
5 Carbide bandsaw blade 3750*35*0.9
6 USA Bimetal bandsaw blade 3780*34*1.1
7 Sharpener for carbide blade and bimetal blade
8 Log hook
9 Iron frame export packing











































Working video link:

SW26G  : https://youtu.be/nVnT95us8bY

SW26E : https://youtu.be/d5HQyGSbeLA

SW26G Gasoline Portable Band Sawmill Machine For Wood Cutting, Log Cutting Mobile Sawmill 0SW26G Gasoline Portable Band Sawmill Machine For Wood Cutting, Log Cutting Mobile Sawmill 1

SW26G Gasoline Portable Band Sawmill Machine For Wood Cutting, Log Cutting Mobile Sawmill 2
