CNC Automatic Horizontal Wood Band Saw, Cheap price portable sawmill machine
| Place of Origin | shandong province, China |
|---|---|
| Brand Name | SH |
| Certification | ISO9001 |
| Model Number | MJ700,MJ1000,MJ1300,MJ1600 |
| Minimum Order Quantity | 1 SET |
| Price | US $4,200 - 10,200 / Set |
| Packaging Details | Wooden crates or iron frame packings |
| Delivery Time | within 15 days |
| Payment Terms | T/T or L/C at sight, Western Union |
| Supply Ability | 1000sets/year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Name | Bandsaw Sawmill | Condition | New |
|---|---|---|---|
| Type | Horizontal Band Saw Mill Wood Log Cutting Machine | Voltage | 380V Or Others |
| Saw Wheel Diameter | 700MM | Max. Sawing Log Width | 1600mm |
| Sawing Log Length | 4.5meters Or Extending Rail Length | Feeding | Manual Or Frequency |
| Saw Head Lifting Up/down | Electrical | Weight | 1100-1500kgs |
| Warranty | 1 Year | After-sales Service Provided | Online Support,commissioning And Training |
Product Description
Portable Horizontal Band Sawmill (Electric Model )
Portable horizontal band saw which is easy to install and operate. Finished with Carbide band saw blade for hard wood cutting . The sawing kerf is small, reduce the waste to high output.
The computerized sawmill is sutiable for cutting expensive wood in the furniture factory and move around to cut wood in virgin forest .
Horizontal Portable Band Sawmill With Electric Motor
| Specifications: | ||||
|
Technical Parameter |
MJ700E | MJ1000E | MJ1300E | MJ1600E |
|
Max. Sawing Wood Diameter |
700MM | 1000MM | 1300MM | 1600MM |
|
Saw Wheel Diameter |
600MM | 700MM | 700MM | 700MM |
|
Sawn Thickness |
2-250MM | 2-300MM | 2-300MM | 2-300MM |
|
Sawing Wood Length MM |
1300-4500 | 1300-4500 | 1300-4500 | 1300-4500 |
|
Main Motor Power |
15KW | 18.5KW | 22KW | 30KW |
|
Lifting Motor Power |
1.1KW | 1.1KW | 1.1KW | 1.1KW |
|
Total Weight (KG) |
1100 | 1100 | 1300 | 1500 |
Optional parts:
- Saw head manually walking forward/back, changes to frequency auto walking
- Saw head manually walking forward/back, changes to frequency auto walking; Saw head electrical setting sawn sizes change to PLC Touching screen auto setworks .
- Extending rail length
- Wheel+ brackets for mobile usage
- Hydraulic log loading arm
Auxiliary Machines:
| Item | Auxiliary Equipment | ||||
| 1 | MR1111 Automatic Band Saw Blade Sharpener | ||||
| 2 | Sand Wheel For MR1111 | ||||
| 3 | UN65 Flash Seal Welding Machine | ||||
| 4 | MR417 Roll Machine | ||||
| 5 | Dual Tooth Setter | ||||
| 6 | USA Lenox Bi-Metal Blade For MJ700 5500*54*1.07mm | ||||
| USA Lenox Bi-Metal Blade For MJ1000 6100*54*1.07mm | |||||
| USA Lenox Bi-Metal Blade For MJ1300 6600*54*1.07mm | |||||
| USA Lenox Bi-Metal Blade For MJ1600 7100*54*1.07mm | |||||
| 7 | Wood Cant Hook 48” Handle |
||||
