Portable Horizontal Band Sawmill
Portable Horizontal Band Sawmill is to meet the requirements of customers in Africa and SouthAmerica .
It is simple installation , easy operation , labor saving and high productivity .
This machine can be drived by either electric motor or diesel engine .
It's widely used by the timber process enterprises in the virgin forests area .
This product is quite popular in Africa , South America , and Eastern Europe , etc .
| Cheap Price Portable Horizontal Band Sawmill | ||||
| Technical Parameter | SH-27E | SH-27G | SH-27D | SH-27K |
| Sawing Wood Diameter | 680 | |||
| Saw Wheel Diameter | 500 | |||
| Sawing Wood Thickness | 10-150MM | |||
| Sawing Wood Length | 800-3800mm | |||
| Motor/Engine Power |
7.5KW Electric |
13HP LONCIN Gasoline | 13HP SPARK Diesel |
14 HP KOHLER Gasoline |
| Packing Size | 2200*1050*1800MM | |||
| Total Weight (KG) | 650 kg | |||
Diesel Engine Powered Horizontal Portable Band Sawmill
|
Technical Parameter |
MJ700D | MJ1000D | MJ1300D | MJ1600D |
|
Sawing Wood Diameter |
700MM | 1000 | 1300 | 1600 |
|
Saw Wheel Diameter(MM) |
600 | 700 | 700 | 700 |
|
Sawing Wood Thicknes |
10-200 | 10-300 | 10-300 | 10-300 |
|
Sawing Wood Length (MM) |
1300-4500 | 1300-4500 | 1300-4500 | 1300-4500 |
|
Engine |
14HP Diesel | 22HP Diesel | 25HP Diesel | 27HP Diesel |
|
Band Saw Blade Length |
5500 | 6100 | 6600 | 7100 |
|
Machine Length(MM) |
5800 | 5800 | 5800 | 5800 |
|
Total Weight (KG) |
800 | 1100 | 1300 | 1500 |
|
Electric Powered Portable Horizontal Band Sawmill |
||||
|
Technical Parameter |
MJ700E | MJ1000E | MJ1300E | MJ1600E |
|
Max. Sawing Wood Diameter |
700MM | 1000MM | 1300MM | 1600MM |
|
Saw Wheel Diameter |
600MM | 700MM | 700MM | 700MM |
|
Sawing Wood Thickness |
10-200MM | 10-300MM | 10-300MM | 10-300MM |
|
Sawing Wood Length MM |
1300-4500 | 1300-4500 | 1300-4500 | 1300-4500 |
|
Main Motor Power |
7.5KW | 11KW | 15KW | 18.5KW |
|
Lifting Motor Power |
1.1KW | 1.1KW | 1.1KW | 1.1KW |
|
Total Weight (KG) |
600 | 1100 | 1300 | 1500 |
Auxiliary Parts Optional :
| Item | Auxiliary Equipment | ||||
| 1 | MR1111 Automatic Band Saw Blade Sharpener | ||||
| 2 | Sand Wheel For MR1111 | ||||
| 3 | UN65 Flash Seal Welding Machine | ||||
| 4 | MR417 Roll Machine | ||||
| 5 | Dual Tooth Setter | ||||
| 6 | USA Lenox Bi-Metal Blade For MJ700 5500*54*1.07mm | ||||
| USA Lenox Bi-Metal Blade For MJ1000 6100*54*1.07mm | |||||
| USA Lenox Bi-Metal Blade For MJ1300 6600*54*1.07mm | |||||
| USA Lenox Bi-Metal Blade For MJ1600 7100*54*1.07mm | |||||
| 7 | Wood Cant Hook 48” Handle | ||||
