Detail Information

Name:	Rip Saw	Sawing Panel Width:	250mm
Sawing Panel Thickness:	120mm	Main Motor:	22KW X 2sets
Circular Blade Diameter:	230mm	Feeding:	Frequency Auto Feeding And Speed Adjustable
Blade Quantity:	2-10pcs	Blade Cooling:	Shaft Center Water Spraying
Operation:	Automatic	Guarantee:	1 Year
After-sales Service:	Video Technical Support, Spare Parts
Highlight:	250mm Panel Ripping Saw Machine , 22KW Ripsaw Sawmill , Ripping Saw Machine 22KW

Product Description

SH120-250 Multi Blade Saw Multiple Rippping Saw Machine for Wood panel board cutting

Double Spindle Panel Cutting Multiple Blades Rip Saw

Introduction:

1. With Inverter auto feeding

2. With carbide blade for hardwood cutting

3. With spindle center spraying water to cool blade

4. With automatic panel controlling

5. Sawing width/thickness can be done as customer needs

6. Can change big motor as customer needs

Specifications:

Multi Blades Rip Saw- For wood panels/plank cutting

Model	SH60-300	SH80-300	SH100-300	SH120-300	SH150-300
Max. Sawing width	250-300mm	250-300mm	250-300mm	250-300mm	250-300mm
Max. Sawing thickness	60mm	30-80mm	40-100mm	50-120mm	60-150mm
Motor	18.5KW/22KW	22KW*2	22KW*2	22KW*2	30KW*2
Saw Blade Diameter	150MM	180mm	210mm	230mm	255mm
Spindle Diameter	50mm	50mm	50mm	50mm	50mm
Weight	1190kg	1260kg	1420kg	1560kg	1620kg

250mm Panel Ripping Saw Machine 22KW Ripsaw Sawmill SH120-250 0

250mm Panel Ripping Saw Machine 22KW Ripsaw Sawmill SH120-250 2

Double Spindle Panel Cutting Multiple Blades Rip Saw -Heavy Duty Type

Model	SH100-400	SH120-400	SH160-400	SH200-400	SH250-400	SH270-400	SH290-400
Sawing width	350-400mm	350-400mm	350-400mm	350-400mm	350-400mm	350-400mm	350-400mm
Sawing thickness	40-100mm	50-120mm	70-160mm	90-200mm	110-250mm	130-270mm	150-290mm
Motor	30kw*2	37kw*2	37/45kw	37/45kw	45kw*2	45/55kw	55KW*2
Saw Blade Diameter	180MM	230mm	255mm	230mm	280mm	280mm	380mm
Spindle Diameter	70mm	70mm	70mm	80mm	80mm	80mm	100mm
Weight	2330kg	2450kg	2480kg	2550kg	2580kg	2620kg	2700kg

250mm Panel Ripping Saw Machine 22KW Ripsaw Sawmill SH120-250 3

250mm Panel Ripping Saw Machine 22KW Ripsaw Sawmill SH120-250 5

Automatic Multi Rip Saw production Line

250mm Panel Ripping Saw Machine 22KW Ripsaw Sawmill SH120-250 6

Multi Blades Rip Saw

Introduction:

with Infrared positioning
for board edges cutting
sawing planks into small pcs
easy usage, no installation

Technical data :

Model	HW500	HW800
Sawing thickness	15-50mm	15-50mm
Sawing width	500mm	800mm
Circular blade diameter	210mm	210mm
Electric motor	15KW	18.5KW
Blade qty	1P-6P	1P-10P
Rotation speed	3500/min	3500/min

Photos:

250mm Panel Ripping Saw Machine 22KW Ripsaw Sawmill SH120-250 7

Heavy Duty Single Shaft Multi Blade Rip Saw / Board Edger Saw Machine

Introduction:

with Infrared positioning
for big thickness board edger cutting
high working efficiency, low cost ,fulfil the max. value of the wood
easy usage, no installation

Technical data :

Model	ZHW800-70	ZHW800-80	ZHW800-100
Sawing wood height	10-70mm	10-80mm	20-100mm
Sawing wood width	800mm	800mm	800mm
Carbide blade diameter	280mm	305mm	355mm
Main motor	22KW	30KW	37KW
Blade quantity	1P-10P	1P-10P	1P-10P
Rotation speed	3500/min	3500/min	3500/min

250mm Panel Ripping Saw Machine 22KW Ripsaw Sawmill SH120-250 9

Tag:

Place of Origin:	Shandong Province, China
Brand Name:	SH
Certification:	ISO9001
Model Number:	SH120-250, SH160-250, SH160-400，SH160-300, etc

Minimum Order Quantity:	1 unit
Price:	$3,000 - $15,000 / Sets
Packaging Details:	container loading
Delivery Time:	within 15 days
Payment Terms:	T/T or L/C at sight
Supply Ability:	1000 units/year
