China Multiple Heads Horizontal Band Resaw machine cut logs straight into planks

Place of Origin Shandong Province, China
Brand Name SH
Certification ISO9001
Model Number 1, 2, 3, 4, 5, 6 heads, etc
Minimum Order Quantity 1 SET
Price USD10,000 ~USD30,000/set
Packaging Details container loading
Delivery Time within 25 days
Payment Terms T/T or L/C at sight, Western Union
Supply Ability 100 Set/Sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Multiple Head Horizontal Band Resaw Machine Condition New
Operation Automatic Motor Power 15kw X 2set, 3sets, 5sets...
Sawing Max. Width 300mm To 600mm As Customized Sawing Height 2to 300mm
Warranty 12 Months After-sales Service Provided Engineers Available To Service Machines Overseas
Leave a Message
Product Description

Multiple Heads Horizontal Resaw Band Saws

This machine is invented by our company.It is easy-operated,high efficiency and easy-installed.

The head quantity is given option from one to six .The user will get multi board at one time to improve the efficiency.

Main Features:

1.The head quantity from one to six is available.

2.Touch screen setting sawing thickness.

3.Variable Frequency Speed Adjustable Feeding Speed.

Technical specifications DT300-1 DT300-2 DT300-3 DT300-5 DT300-6
Sawing width 300mm 300mm 300mm 300mm 300mm
Minimum wood thickness 2mm 2mm 2mm 2mm 2mm
Maximum wood height 260mm 260mm 260mm 260mm 260mm
Band wheel diameter 700mm 700mm 700mm 700mm 700mm
Saw motor 15kw 15kw x 2 15kw x 3 15kw x 5 15kw x 6
Saw machine length 3500mm 4500mm 5800mm 8500mm 11000
Weight 900kg 1500kg 2200kg 3500kg 5000kg
Feeding Variable frequency speed adjustable conveyor
Operation Touching screen auto setworks for sawn thickness
