Computer automatic Twin Blades Circular Saw /Wood Sliading Table Circular Sawmill Machine

Place of Origin shandong province
Brand Name SH
Certification ISO9001
Model Number TT1500, TT2000,TT3000,CT1500,CT3000
Minimum Order Quantity 1 SET
Price US $3,000 - 9,800 / Set
Packaging Details iron made frame pallet
Delivery Time within 15 days
Payment Terms T/T, L/C, Western Union
Supply Ability 2000sets/year

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition New Type Circular Saw
Voltage 380v/3phase/50HZ Or As Customer Needs Usage Woodworking
Warranty 12 Months Cutting Log Dia. 48CM
Operation Manual Or Digital Auto Control Power(W) 7.5kw X 2
Style Vertical Motor Power Electric Or Diesel Engine
Leave a Message
Product Description

Twin Blades Circular Sliding Table Sawmill

The round log can slitting naturally,slitting totally,can sawing round wood to square timber.

The circular saw blade can avoid band saw blade bending,or dig hole on wood.

The round log table saw mill is high safety ,high flatness of sawing surface,suitable for short wood,hard wood,large diameter wood.

The production capacity is more than 4 timers than band sawmill.

The specification is adjustable,Convenient to move the running rule,accuracy.

The track use linear guideway,accuracy,no error,wear resistent.

The machine have 2 separate motors,separate switches,Can only use one motor when sawing small diameter wood log.

Wood Sliding Table Sawmill (Computer Type)



Model CT1500 CT2000 CT3000
Max Sawing Wood Diameter 400mm 400mm 400mm
Max Sawing Wood Length 1500mm 2000mm 3000mm
Saw Blade Diameter 500mm 500mm 500mm
Motor Power 7.5KW*2 7.5KW*2 7.5KW*2
Rail Length 3500mm 5000mm 6500mm
Wood Fasten Model Pneumatic up/down Pneumatic up/down Pneumatic up/down
Carriage Rail Model Linear Axis Linear Axis Linear Axis
Feeding mode Electric frequency variable speed adjustable
Operation PLC touching screen automatic operation

Optional part:

1.Maximum sawing log diameter is upto 48cm .

2.When cutting very hardwood we can increase motor power as customer needs .

Computer automatic Twin Blades Circular Saw /Wood Sliading Table Circular Sawmill Machine 0



Wood Sliding Table Sawmill (Manual type )

Model TT1500 TT2000 TT3000
Max Sawing Wood Diameter 400mm 400mm 400mm
Max Sawing Wood Length 1500mm 2000mm 3000mm
Saw Blade Diameter 500mm 500mm 500mm
Motor Power 7.5KW*2 7.5KW*2 7.5KW*2
Rail Length 3500mm 5000mm 6500mm
Wood Fasten Model Pneumatic up/down Pneumatic up/down Pneumatic up/down
Carriage Rail Model Linear Axis Linear Axis Linear Axis

Computer automatic Twin Blades Circular Saw /Wood Sliading Table Circular Sawmill Machine 1

Computer automatic Twin Blades Circular Saw /Wood Sliading Table Circular Sawmill Machine 2
