1200mm Wood Vertical Band Sawmill MJ3212 MJ3212B Wood Cutting Bandsaw

1 SET

MOQ

US $3,000 - 50,000 / Set

Price

1200mm Wood Vertical Band Sawmill MJ3212 MJ3212B Wood Cutting Bandsaw

Features Gallery Product Description Request A Quote

Features

Specifications

Name: Vertical Band Saw Cutting Machine

Usage: Wood Logs Or Planks Cutting

Max. Sawing Log Diameter: 1200mm

Max. Sawing Log Length: 6meters

Carriage Moving Forward/back: Frequency

Carriage Moving Right/left: Automatic

Log Rotation: Hydraulic Chain Roation

Capacity: 100-150m3/day

Highlight:

1200mm Wood Vertical Band Sawmill

,

MJ3212B Wood Cutting Bandsaw

,

MJ3212 Wood Cutting Bandsaw

Basic Infomation

Place of Origin: Shandong Province, China

Brand Name: SH

Certification: ISO9001

Model Number: MJ3212B-Z5000,MJ3212B-Z3000,MJ3210-Z5000,MJ3310-Z3000

Payment & Shipping Terms

Packaging Details: container loading

Delivery Time: within 25 days

Payment Terms: T/T or L/C at sight, Western Union

Supply Ability: 1000sets/year

Gallery

1200mm Wood Vertical Band Sawmill MJ3212 MJ3212B Wood Cutting Bandsaw

Product Description

Vertical band saw cutting machine price wood cutting sawmill machine for log diameter upto 1200mm

MJ3212 &MJ3212B Vertical Band Sawmill With CNC Log Carriage

This lathe is mainly used to Vertical cut or slab-cut logs of a large or middle diameter or re-saw timbers into slabs and square logs of various specifications and it smoothly runs at a high efficiency.
In combination with carriage, it will enlarge the working range and improve product quality and hence is the ideal equipment for wood working enterprises.

1.MJ3212 CNC vertical band sawmill with automatic log carriage

Technical data	MJ3212-ZD3000	MJ3212-ZD5000
Saw wheel diameter	1250mm	1250mm
Maximum sawing log diameter	1200mm	1200mm
Maximum sawing log length	4meters	6meters
Main motor	37KW	37KW
Saw blade LWT	8600x150x1.25mm	8600x150x1.25mm
Carriage clip stake quantity	3sets	4sets
Wood grasp mode	Electric	Electric
Carriage walking/advance	Frequency converter	Frequency converter
Setting sawn size	PLC touching screen	PLC touching screen
Carriage length	3meters	5meters
Rail length	10meters	18meters
Weight	7500kgs	8000kgs

2. MJ3212B Vertical Band Saw with CNC Automatic Log Carriage

Technical data	MJ3212B-ZD3000	MJ3212B-ZD5000
Saw wheel diameter	1250mm	1250mm
Maximum sawing log diameter	1500mm	1500mm
Maximum sawing log length	4meters	6meters
Main motor	45KW	45KW
Saw blade LWT	9200x150x1.25mm	9200x150x1.25mm
Carriage clip stake quantity	3sets	4sets
Wood grasp mode	Electric	Electric
Carriage walking/advance	Frequency converter	Frequency converter
Setting sawn size	PLC touching screen	PLC touching screen
Carriage length	3meters	5meters
Rail length	10meters	18meters
Weight	11000kgs	12000kgs

1200mm Wood Vertical Band Sawmill MJ3212 MJ3212B Wood Cutting Bandsaw 0

1200mm Wood Vertical Band Sawmill MJ3212 MJ3212B Wood Cutting Bandsaw 1

Platform Woodwork Band Saw

Technical parameters	MJ328		MJ329	MJ3210	MJ3310	MJ3212
Diameter of saw wheel		800mm	900mm	1000mm	1070mm	1250mm
Width of saw wheel		110mm	120mm	120mm	120mm	140mm
Rotational speed of saw wheel		750r·p·m	750r·p·m	750r·p·m	750r·p·m	750r·p·m
saw wheel, saw clip elevation		Manual	Manual	Automatic	Automatic	Automatic
Length of blade		5700mm	6400mm	6800mm	7400mm	8600mm
Max. diameter of log sawed		650mm	750mm	900mm	1000mm	1200mm
Main motor power		11kw	15kw	22kw	30kw	37kw
weight		1000kg	1300kg	1600kg	1800kg	3200kg
1,include Main motor power 2,include band saw blade 1 Article 3,include Iron-made safe protective casing 4,include Manual lubrication system 5,include Foundry work platform

1200mm Wood Vertical Band Sawmill MJ3212 MJ3212B Wood Cutting Bandsaw 2

1200mm Wood Vertical Band Sawmill MJ3212 MJ3212B Wood Cutting Bandsaw 3
