MJ3310 Vertical Band Sawmill with Log Carriage / Wood vertical cutting bandsaw mill with sports car
| Place of Origin | shandong province |
|---|---|
| Brand Name | SH |
| Certification | ISO |
| Model Number | MJ3310-DD5000,MJ3310-ZD3000,MJ3310-ZD5000 |
| Minimum Order Quantity | 1 SET |
| Price | US $9,300 - 18,000 / Set |
| Packaging Details | container loading |
| Delivery Time | within 15 days |
| Payment Terms | T/T or L/C at sight, Western Union |
| Supply Ability | 1500sets/year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Type | Band Saw | Use | Woodworking |
|---|---|---|---|
| Style | Vertical | Condition | New |
| Voltage | 380v,50HZ ,3phase Or As Requested | Main Motor Power(W) | 30kw |
| Warranty | 12 Months | After-sales Service Provided | Engineers Available To Service Machine Overseas |
| Cutting Log Maximum Diameter | 1000mm | Cutting Log Length | 4m/6m Or As Customer Needs |
| Feeding | Electric Or Frequency Variable | Operation | Electric Or PLC Touching Screen Auto Setworks |
| Log Grasp | Manual Or Electric |
Product Description
MJ3310 Vertical Band Sawmill with Log Carriage
1.MJ3310 Vertical band sawmill with electric log carriage
| Technical data | MJ3310-DD3000 | MJ3310-DD5000 |
| Saw wheel diameter | 1070mm | 1070mm |
| Maximum sawing log diameter | 1000mm | 1000mm |
| Maximum sawing log length | 4meters | 6meters |
| Main motor | 30KW | 30KW |
| Saw blade L*W*T | 7400x150x1.05mm | 6850x125x1.05mm |
| Carriage clip stake quantity | 3sets | 4sets |
| Wood grasp mode | Manual | Manual |
| Carriage walking/advance | Electric | Electric |
| Setting sawn size | Electric | Electric |
| Carriage length | 3meters | 5meters |
| Rail length | 10meters | 18meters |
| Weight | 4500kgs | 6000kgs |
2. MJ3310 Vertical band sawmill with CNC log carriage
| Technical data | MJ3310-ZD3000 | MJ3310-ZD5000 |
| Saw wheel diameter | 1070mm | 1070mm |
| Maximum sawing log diameter | 1000mm | 1000mm |
| Maximum sawing log length | 4meters | 6meters |
| Main motor | 30KW | 30KW |
| Saw blade L*W*T | 7400x150x1.05mm | 7400x150x1.05mm |
| Carriage clip stake quantity | 3sets | 4sets |
| Wood grasp mode | Electric | Electric |
| Carriage walking/advance | Frequency converter | Frequency converter |
| Setting sawn size | PLC touching screen | PLC touching screen |
| Carriage length | 3meters | 5meters |
| Rail length | 10meters | 18meters |
| Weight | 4500kgs | 6000kgs |
