400mm Width Wood Planks Sawmill Rip Saws For Woodworking

  • 400mm Width Wood Planks Sawmill Rip Saws For Woodworking
  • 400mm Width Wood Planks Sawmill Rip Saws For Woodworking
  • 400mm Width Wood Planks Sawmill Rip Saws For Woodworking
  • 400mm Width Wood Planks Sawmill Rip Saws For Woodworking
  • 400mm Width Wood Planks Sawmill Rip Saws For Woodworking
  • 400mm Width Wood Planks Sawmill Rip Saws For Woodworking
  • 400mm Width Wood Planks Sawmill Rip Saws For Woodworking
Place of Origin Shandong Province, China
Brand Name SH
Certification ISO9001
Model Number SH80-300, SH120-300,SH250-400,SH290-400,SH150-400, etc
Minimum Order Quantity 1 SET
Price US $3,000 - 15,000 / Set
Packaging Details wooden pallet or iron frame packing
Delivery Time within 20 days
Payment Terms T/T or L/C at sight, Western Union
Supply Ability 100sets/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Condition New Type Rip Saw
Max. Sawing Width 400mm Max. Sawing Height 160mm
Voltage 380V/3phase/50HZ,440V, Or As Cusmer Needs Main Electric Power 37kw X 2
Blade Diameter 355mm Warranty 12 Months
Operation Automatic Feeding Type Auto Feeding
High Light

Wood Planks Sawmill Rip Saws

,

Sawmill Rip Saws For Woodworking

,

400mm Width Sawmill Rip Saws
Leave a Message
Product Description

Wood planks Cutting Multiple blade circular sawmill multiple rip saw mill

Multi Blades Ripsaw for Planks/Lumber Cutting

1.Cut planks into smaller wood boards at several pieces per time.
2.Automatic controlling

1.Used for Lumber/Panels/Planks Cutting

2.Max. cutting depth/thciness is upto 160mm

3.Max. cutting width is upto 400mm

4.Big motor power, fit for hardwood cutting

5.Blades is placed on up/down abrod/spindle .

6.We present one set discs on your cutting thickness



Specifications:

Multi Blades Rip Saw- For wood panels/plank cutting

Model
SH60-300
SH80-300
SH100-300
SH120-300
SH150-300
Max. Sawing width
250-300mm
250-300mm
250-300mm
250-300mm
250-300mm
Max. Sawing thickness
60mm
30-80mm
40-100mm
50-120mm
60-150mm
Motor
18.5KW/22KW
22KW*2
22KW*2
22KW*2
30KW*2
Saw Blade Diameter
150MM
180mm
210mm
230mm
255mm
Spindle Diameter
50mm
50mm
50mm
50mm
50mm
Weight
1190kg
1260kg
1420kg
1560kg
1620kg

400mm Width Wood Planks Sawmill Rip Saws For Woodworking 0400mm Width Wood Planks Sawmill Rip Saws For Woodworking 1



Double Spindle Panel Cutting Multiple Blades Rip Saw -Heavy Duty Type

Model
SH100-400
SH120-400
SH160-400
SH200-400
SH250-400
SH270-400
SH290-400
Sawing width
350-400mm
350-400mm
350-400mm
350-400mm
350-400mm
350-400mm
350-400mm
Sawing thickness
40-100mm
50-120mm
70-160mm
90-200mm
110-250mm
130-270mm
150-290mm
Motor
30kw*2
37kw*2
37/45kw
37/45kw
45kw*2
45/55kw
55KW*2
Saw Blade Diameter
180MM
230mm
255mm
230mm
280mm
280mm
380mm
Spindle Diameter
70mm
70mm
70mm
80mm
80mm
80mm
100mm
Weight
2330kg
2450kg
2480kg
2550kg
2580kg
2620kg
2700kg



400mm Width Wood Planks Sawmill Rip Saws For Woodworking 2400mm Width Wood Planks Sawmill Rip Saws For Woodworking 3



Log Cutting Multi Blade Rip Saw

  • Technical data
Model
SHYM150
SHYM200
SHYM240
SHYM260
SHYM285
SHYM330
Sawing Log Diameter
20-150mm
60-200mm
80-240mm
100-260mm
130-285mm
150-330mm
MinSawing Log Length
600mm
600mm
600mm
600mm
600mm
600mm
Main Motor power
18.5KW*2
22KW*2
30KW*2
30/37KW
30/37KW
37KW*2
Spindle Diameter
50mm
50mm
60mm
60mm
60mm
70mm
Saw Blade Diameter
255mm
305mm
355mm
380mm
405mm
450mm
Weight
1570KG
1720KG
2200KG
2300KG
2350KG
2550KG
Model
SHYM340
SHYM360
SHYM400
SHYM430
SHYM480
Sawing Log Diameter
150-340mm
170-360mm
180-400mm
200-430mm
250-480mm
Min Sawing Log Length
600mm
600mm
600mm
600mm
600mm
Main Motor power
45KW/55KW
55KW*2
55KW*2
55KW*2
55KW*2
Spindle Diameter
80mm
80mm
80mm
100mm
100mm
Saw Blade Diameter
480mm
500mm
550mm
600mm
650mm
Weight
2650KG
2680KG
3500KG
3880KG
4100KG



400mm Width Wood Planks Sawmill Rip Saws For Woodworking 4

400mm Width Wood Planks Sawmill Rip Saws For Woodworking 5

400mm Width Wood Planks Sawmill Rip Saws For Woodworking 6

Auto Wood Multi Rip Saw Production Line

  • The production line will increase wood processing speed and only need 3-5 workers for more economic profit.
  • The max sawing log diameter is 350-450mm.
  • We can design the production line according to the diameter of your logs.
