SH120-400 Double Arbor Multiple RipSaw, Multi Blades Rip Saw Machine from China

Basic Information

Place of Origin:	shandong province, China
Brand Name:	SH
Certification:	ISO9001
Model Number:	SH120-250, SH160-250, SH160-400，SH160-300

Minimum Order Quantity:	1set
Price:	$3,000 - $15,000 / Sets
Packaging Details:	plywood case
Delivery Time:	5-8 work days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	200 Sets per Month

Get Best Price Contact Now

Detail Information

Name:	Multiple Ripsaw	Condition:	New
Max.sawing Thickness:	120mm	Max. Sawing Width:	400mm
Feeding:	Frequency Auto Feeding And Speed Adjustable	Blade Cooling:	Axis Center Watering
Highlight:	double arbor multi rip saw , multi blade rip saw machine , China multi rip saw machine

Product Description

Double Spindle Panel Cutting Multiple Blades Rip Saw

Introduction:

1. With Inverter auto feeding

2. With carbide blade for hardwood cutting

3. With spindle center spraying water to cool blade

4. With automatic panel controlling

5. Sawing width/thickness can be done as customer needs

6. Can change big motor as customer needs

Specifications:

Model	SH80-300	SH120-250	SH160-250
Max. sawing width	300mm	250mm	250mm
Max. sawing thickness	80mm	120mm	160mm
Min sawing length	600mm	500mm	500mm
Motor power	15kw x2	22kw x2	30kw x2
Saw blade diameter	180mm	230mm	255mm
Machine weight	1200kg	1800kg	2000kg
Model	SH120-300	SH160-300	SH160-400
Max. sawing width	300mm	300mm	400mm
Max. sawing thickness	120mm	160mm	160mm
Min sawing length	600mm	600mm	600mm
Motor power	22kw x2	30kw x2	37kw x2
Saw blade diameter	230mm	280mm	280mm
Machine weight	2500kg	2800kg	3000kg
Feeding	Variable frequency speed adjustable automatic feeding
Cooling blade	Spindle center water cooling blade

SH120-400 Double Arbor Multiple RipSaw, Multi Blades Rip Saw Machine from China 0

SH120-400 Double Arbor Multiple RipSaw, Multi Blades Rip Saw Machine from China 2
