Large Wood Shavings Machine For Animal Bedding 4000kgs Per Hour
| Place of Origin | Shandong Province, China |
|---|---|
| Brand Name | SH |
| Certification | ISO9001 |
| Model Number | SHBH500-2,SHBH500-4,SHBH500-6, SHBH1000-4 |
| Minimum Order Quantity | 1 SET |
| Price | US $ 4,300 - 12,600 / Set |
| Packaging Details | wooden pallet or iron frame packings |
| Delivery Time | within 20 days |
| Payment Terms | T/T or L/C at sight, Western Union |
| Supply Ability | 1000sets/year |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Condition | New | Application | Make Wood Shavings |
|---|---|---|---|
| Production Capacity | 500-1500kgs/Hour, Or 4000kgs/hour | Warranty | 12 Months |
| Voltage | 380V, 3PHASE/50HZ Or As Customer Needs | Raw Materials | Wood, Log, Tree Branch, Offcuts, Scraps, Etc |
| Axle Quantity | 2 - 6 Pcs | Blade Quantity | 8-24pcs |
| High Light | Large Wood Shaving Machine,4000kgs per Hour Wood Shaving Machine,Animal Bedding Wood Shaving Machine |
||
Product Description
Wood Shaving Machine
Process wood sticks,twigs,branches,wood scraps into shaving.
Adjust the size and thickness of the wood shaving.
It is the material for Plywood,furniture or paper factory.
Add as filler to prevent damage when transport some fragile items.
Use as nest shavings filler in poultry or animal breeding.
Bio-energy ignition material.
| Model | SHBH500-2 | SHBH500-4 | SHBH500-6 |
| Max Processing wood Length | 800MM | 1400MM | 1400MM |
| Max Processing wood Width | 500MM | 500MM | 500MM |
| Shaft Quantity | 2pcs | 4pcs | 6pcs |
| Blade Quantity | 8pcs | 16pcs | 24pcs |
| Speed (r/min) | 3500 | 3500 | 3500 |
| Bucket Length (mm) | 800 | 1400 | 1400 |
| Total Power (kw) | 10.5KW | 23.25KW | 30.75KW |
| Shaving Depth(mm) | 0.2-1 | 0.2-1 | 0.2-1 |
| Production(KG/Hour) | 500 | 1000 | 1500 |
| With pneumatic press cover | |||
Spiral Shaft type Wood Shaving Machine
- Specification
| Model | SHBH500-2-L | SHBH500-4-L | SHBH500-6-L |
| Processing wood max. length(mm) | 800 | 1400 | 1400 |
| Processing max. width/diameter(mm) | 500 | 500 | 500 |
| Spiral Shaft quantity | 2pcs | 4pcs | 6pcs |
| Blade (pcs) | 84 x 2 | 84 x 4 | 84 x 6 |
| Motor speed (rpm) | 3500 | 3500 | 3500 |
| Bin length (mm) | 800 | 1400 | 1400 |
| Total Motor power (kw) | 10.5KW | 23.25KW | 30.75KW |
| Shaving depth (mm) | 0.1-0.5 | 0.1-0.5 | 0.1-0.5 |
| Shavings output | 350KG/H | 700KG/H | 1000KG/H |
| Machine weight | 950kgs | 1800kgs | 2200kgs |
- Image
Large Capacity 4000kgs/hour Wood Shaving Machine
| Model | SHBH1000-4 |
| Processing wood max. length(mm) | 2600 |
| Processing wood max. width(mm) | 1000 |
| Planer Head | 4pcs |
| Blades | 32pcs |
| Rotation speed (r/min) | 3500 |
| Bin length (mm) | 2600 |
| Total motor power (kw) | 108KW |
| Shavings depth /thickness (mm) | 0.2-0.5 |
| Production capacity | 4000KG/小时 |
| Overall dimension | 5600*2100*2200 |
