This machine is widely used in processing wood, such as various types of small-diameter wood, board skin, round core, waste veneer, and various non-wood raw materials, such as various straw, cotton, And so on, for a wide range. Belt feed, can also be customized chain plate conveyor, feed can be more smooth, greatly improve production capacity, is the ideal choice for biological power plant equipment.
Technical specifications:
| SHZH1300-600 Wood Composite Crusher | |
| Feeding Inlet(mm) | 1250*500 |
| Blade shaft Diameter(mm) | 800mm |
| Blades (pcs) | 2 sets |
| Blade Roll Speed (R/Min) | 850 |
| Max processing wood diameter | 450mm |
| Wood Chipper Size | 20-40mm |
| Production Capacity | 15-30tons/Hour |
| Diesel motor | 400HP |
| Feeding conveyor length | 6m |
| Discharging conveyor length | 10m |
| Feeding Suspension Inverter Motor | 7.5KW |
| Chain Plate Feeding Inverter Motor | 11KW |
| Electromagnetic valve integrated Oil Pump Motor | 3KW |
| Conveyor Gear Motor Power | 4KW (gear motor ) |
| Weight | 20tons |
| Overall Size | 8500*2400*2200mm |
| Soft Start Frequency conversion control integrated control cabinet | |
| USD6200 To Add Wheels for mobile usage (Optional ) | |
Working video link: https://youtu.be/hTanrkLlbP8
