Model
|
MJH1000E | MJH700E |
|
Max Sawing Wood Diameter
|
1000mm | 700mm |
|
Saw Wheel Diameter
|
700mm | 700mm |
|
Max Sawing Wood Thickness
|
300mm | 300mm |
|
Standard Sawing Wood Length
|
4000mm | 4000mm |
|
Electric Motor Power
|
30kw | 22kw |
|
Up/Down Electric Motor
|
1.5kw | 1.5kw |
|
Forward/backward Electric Motor
|
2.2kw | 2.2kw |
|
Saw Blade Width
|
27mm-75mm | 27mm-75mm |
|
Blade Tension
|
Hydraulic | Hydraulic |
|
Machine Length
|
5800mm | 5800mm |
|
Weight
|
2500kg | 2300kg |
| Standard Configuration | ||||||
 |
Touch Screen Accuset Setworks Automatically moves head for each cut and head walking speed is Frequency variable |
|
Hydraulic Clamp *1 Secure and stabilize the log |
|||
|
Hydraulic Wood Clamp*4 Secure and stabilize the log |
|
Hydraulic vertical side supports *4 Secure and stabilize the log |
|||
|
Hydraulic Log Loading Arm *1 |
|
Board automatic return hook | |||
| Optional parts: | ||||||
|
Mobile Wheels, 8 Adjustable Up/down legs |
|
Hydraulic bi-directional Chain log turner*2 For max. log control |
|||
|
Hydraulic plank roller axle x1 | |
Extend The Rail Length | |||
